Equipped with cyclone separator, can collect 95% dust
Certified HEPA H12 filter captures up to 99.99% of particles at 0.3 microns(H12)
3 phase Ametek motors with independent on/off
Drop-down dust collection in continuous bag system
Main Features of Integrated Pre-separator vacuum cleaner for concrete floor grinder
1) Motor unit: Three single-phase industry-grade motors with independent ON/OFF, allowing to adjust airflow to suit different requirements.Built-in vacuum meter for real-time filter clogging detection.
2) Filter unit: Equipped with a HEPA (PTFE coated, "TORAY" polyester), the machine can separate 0.3um dust with an efficiency of 99.5%, securing a high standard of quality and safety.
3) Filter cleaning system: The Single-Phase 3.6KW Dust Extractor with Integrated Pre-separator for concrete floor RV5 series uses a unique "reverse-air cleaning" system that cleans the filter very easily in a high efficient way, preventing dust from clogging the filter and thereby maintaining a normal airflow.
4) Equipped with a drop-down continuous bag system for collecting dust, providing very easy handling of grinding residue.
Product parameters：
| Model | RV513 | RV512 |
| Voltage | 110 | 220 |
| Phase | 1 | 1 |
| Max air flow (m³/h) | 485 | 600 |
| Max air flow (CFM) | 290 | 358 |
| Max vacuum (mbar) | 265 | 327 |
| Rated input power (Hp丨kW) | 3.4丨2.4 | 5.1丨3.6 |
| HZ | 50/60 | |
| Filter area (ft²丨㎡) | 38丨3.5 | |
| Filter capacity | Filter capacity: 0.3um, efficiency＞99.5% | |
| Filter cleaning | Manual jet-pulse | |
| Filter type | H12 HEPA filter TORAY polyester | |
| Dimension (inch丨mm) | 41*29*50丨1030*730*1270 | |
| Weight (lbs丨kgs) | 250丨113 | |
Compact and height adjustable.
Manual jet-pulse filter cleaning,optional motor丨drive and timed auto jet丨pulse.
1mm carbon steel barrel, durable and not deform from strong suction.
Reliable silent slides and solid frame for height adjustment.
2 stage filtration
Certified massive filter captures up to 99.99% of particles at 0.3 microns(H12)
3 phase Ametek motors with independent on/off
Drop-down dust collection in continuous bag system
Multiple voltage options to meet different construction needs.
Heavy duty industrial hoover equipped with turbocharged motor for long-time use for large dust.
Height adjustable, easy to transport.
Mute wear-resistant reliable universal wheels and casters.
Certified HEPA H12 filter captures up to 99.99% of particles at 0.3 microns(H12)
Equipped with turbe motor, can run 24 hours a day
Drop-down dust collection in continuous bag system
Automatic jet-pulse cleaning system given by air compressor
